What are Insulation Classes, In Terms of Temperature?
Date: 18-12-24
By: ZTELEC GROUP
As per IEC standard, thermal classes of insulation are defined as having maximum permissible
working temperature as under,:
Class A : 105 °C. These are mostly Cloth, silk, paper impregnated / coated with liquid dielectric
Class B: 130 °C.
Class C: >180°C.
Class E : 120 °C.
Class F : 155 °C
Class H : 180 °C
